 Optical coatings, including High Reflective Coatings and dielectric coatings, are thin films applied to optical components to control their reflectance and transmittance properties.


 These coatings work by interfering with light waves, resulting in constructive or destructive interference depending on the coating thickness and the wavelength of light.



Metallic coatings, such as High Reflective Coatings, offer high reflectance over a wide range of wavelengths, while dielectric coatings provide lower reflectance but can be tailored to specific wavelengths.


 Dielectric coatings are made of materials such as titanium dioxide, tantalum pentoxide, and silicon dioxide. They have lower reflectance than metallic coatings, but they can be designed to reflect or transmit specific wavelengths of light. Dielectric coatings are used in anti-reflection coatings, filters, and other applications where precise control of light is required.


 Optical coatings find widespread applications in various industries, including lasers, telescopes, cameras, and medical devices, due to their ability to enhance optical performance.



Diameter1-100 mm
Diameter Tolerance+0/-0.1 mm
RMS irregularities (RMSi)25 nm
Surface imperfections (Scratch/Dig)40 - 20
Coating

Customer specific(HR, BBHR, laser HR coating and so on)

MeasurementFull-surface interferometric
MaterialCustomer specific (almost any type of glass, quartz glass,  ZERODUR®)
MountingCustomer specific
